| Appearance | |
| Dimension | H163*W28*T19cm |
| Weight | 75kgs(include cable and gun) |
| Cable length | 3.2 meters |
| Installation Method | Floor stand |
| Box Material | Sheet metal |
| Screen | 3.5 inch LCD |
| Electrical Features | |
| Input | 100VAC-400VAC+/-20% |
| Input frequency | 50Hz/60Hz |
| Rated power | 7/11/14/22/43kw |
| Precision | Level 1 |
| Output Voltage | 100VAC-400VAC+/-20% |
|
Output Current |
7kw-single phase 32A 11kw-three phase 16A 14kw-single phase 64A 22kw-three phase 32A 43kw-three phase 64A |
| Consumption | <2w |
| Functional Features | |
| User Interface | Emergency Stop/LCD touch screen/LED indicator/RFID |
| Safety Features | Overvoltage/undervoltage protection, overload protection, leakage protection, etc |
| Internet Connection | Ethernet (wifi/4g as option) |
| Working environment | |
| Working latitude | <2000m |
| Working temperature | -30° C～+65° C |
| Working humidity | 5 %~ 95% |
| Protection level | IP54 |
| Cooling | Natural cooling |
| MTBF | 100,000 Hours |
| Safety standards | IEC61851-1/2017 |
| Special protection | Anti-UV protection |
